EN-6 SCOUT PRO
No. Designation Function
1. Feet
1
Provides leveling for certain models.
2. Spirt Level
1
Provides level indication.
3. Platform Weighing platform, either round or rectangular.
4. PRINT Unit button Prints data, scrolls through units, steps through units.
5. Display LCD display with ICONS.
6. Lockswitch Locks certain menu functions, located under balance.
7. ON/ZERO Off button On/Off, Zero, enters menu, accepts menu settings.
8. USB or RS232 port Optional kit for either RS232 operation or USB.
9. Security Bracket Part of balance for optional external cable and lock.
10. Power Input Jack Connector for AC adapter.
11. 7-segment LCD Part of 6-digit LCD display.
12. Brackets Auxilliary indication.
13. G (not used)
14. N (not used)
15. % Indicates percent weighing.
16. PC Indicates pieces during parts counting.
17. kg Indicates weight in kilograms.
18. dwt Indicates weight in pennyweights.
19. g Indicates weight in grams.
20/22. oz t Indicates weight in troy ounces.
21. t Indicates weight in taels or totalize mode.
22. oz Indicates weight in ounces.
23/22. lb:oz Indicates weight in pound:ounces.
23. lb Indicates weight in pounds.
24. Decimal point.
25 Stability indicator, indicates stable weight.
26. Negative sign.
27. (not used)
28. Battery indicator flashes when battery is down to
approximately 20 minutes of power remaining.
*
-
NOTES: 1. Certain models are provided with leveling feet and spirit level.
2. Unit measurement varies by model.
