11
REBUILD AIR SPRING CARTRIDGE
10. Remove the old air valve schrader (18607-01) from the base
cap.
11. Install a new air valve schrader (18607-01) into the base cap.
12. Use a socket wrench with a hex socket 28 mm (18860-01) or a
cassette lockring tool to remove the top cap.
13. Remove the old o-ring (00338-68) from the top cap. Clean using
disc brake cleaner and a paper cloth or rag to remove old thread
sealant.
14. Install a new o-ring (00338-68) on the top cap. Apply assembly
grease on o-ring.
12
13 14
10 11
