VCL 1508
EN
APPLIANCE DESCRIPTION (Fig. F1)
FILTERING SYSTEMS AND ACCESSORIES (Fig. F1)
TECHNICAL DATA
PREPARING THE APPLIANCE
• Power supply: ..................................................230V~ 50/60Hz
• Power: ................................................................700W
• Dust capacity: ..................................................3 L
• Cable length: ...................................................4.8m
• Auto rewind wire
• Easy to clean
• Bagless
Before starting , correctly connect the exible hose to the appliance:
• Insert the exible hose (16) sleeve (19) in the air aspiration connection (3) and turn it
counterclockwise. (Fig. F2)
• Turn it clockwise to remove the sleeve (19). (Fig. F3)
• Insert the telescopic extension (20) in the ergonomic handle (17). (Fig. F4)
• If desired, insert the multi-functional brush (21) in the telescopic extension (20). (Fig. F5)
• Adjust the telescopic extension (20) by pushing the cursor (20a) forward. (Fig. F6)
1) Motor body
2) Handle
3) Air aspiration connection
4) Dust container
4a) Lid opening button
5) Wheel
6) Multi-directional wheel
7) Air outlet grid
8) Container release button
9) Power cord
10) Multi-functional brush hooking slot
11) Cord winder button
12) ON/OFF switch
14) Net lter
14a) HEPA lter
14b) Round lter
15) HEPA air outlet lter
16) Flexible hose with ergonomic handle
17) Ergonomic handle
17a) Air ow manual regulator
18) 2 positions nozzle: lance/dust brush
19) Sleeve
20) Metallic telescopic extension
21) Multi-functional brush
21a) Parquet/oor switch
