3. Parts replacement
44983601TH Rev.1
3-10 /
3.3.5 Cover-Side-L
(1) Remove the cassette.
(2) Open MPT, the Cover-Assy-Stacker and the Cover-Assy-Rear.
(3) Disengage the four tabs (a to d) and remove Cover-Side-L
by opening it from the front side of the
printer in the direction of the arrow.
(4) Installing is performed by the inverse procedure with removing.
①
a
b
c
d
