Oki B431L6

7. Connection Diagram
Oki Data CONFIDENTIAL
44983601TH Rev.1
7-5 /
PinNo. I/O Signal Function
56 VDD LogicPower
57 VSS Logic Ground
58 ODT0 ODTControl0
59 DM0 DataMask0
60 CKE0 ClockEnable0
61 VSS Logic Ground
62 /WE /Write Enable
63 DQ4 Data Bus4
64 VDD LogicPower
65 DQ5 Data Bus5
66 - NC Notused
67 VSS Logic Ground
68 BA1 BankSelect1
69 DQ6 Data Bus6
70 A10/AP AddressBus10/AddressBusP
71 DQ7 Data Bus7
72 VDD LogicPower
73 VSS Logic Ground
74 A3 AddressBus3
75 DQ8 Data Bus8
76 A7 AddressBus7
77 DQ9 Data Bus9
78 - NC Notused
79 VSS Logic Ground
80 VDD LogicPower
81 DQ10 Data Bus10
82 - NC Notused
83 DQ11 Data Bus11
84 A8 AddressBus8
85 VSS Logic Ground
86 A4 AddressBus4
87 /DQS1 /DataStrobe1
88 VDD LogicPower
89 DQS1 DataStrobe1
90 A0 AddressBus0
91 VSS Logic Ground
92 BA2 BankSelect2
93 DM1 DataMask1
94 /S0 /S0
95 VSS Logic Ground
96 VDD LogicPower
97 DQ12 Data Bus12
98 /RAS /LowAddressStrobe
99 DQ13 Data Bus13
100 VSS Logic Ground
101 VSS Logic Ground
102 CK1 Clock1
103 DQ14 Data Bus14
104 /CK1 /Clock1
105 DQ15 Data Bus15
106 VSS Logic Ground
107 VSS Logic Ground
108 - NC Notused
109 - NC Notused
110 VDD LogicPower
111 - NC Notused
112 BA0 BankSelect0
113 VSS Logic Ground
114 A1 AddressBus1
115 - NC Notused
