Oki B431L6

7. Connection Diagram
Oki Data CONFIDENTIAL
44983601TH Rev.1
7-6 /
PinNo. I/O Signal Function
116 A5 AddressBus5
117 - NC Notused
118 VDD LogicPower
119 VSS Logic Ground
120 A9 AddressBus9
121 - NC Notused
122 A12 AddressBus12
123 - NC Notused
124 VDD LogicPower
125 VSS Logic Ground
126 - NC Notused
127 - NC Notused
128 - NC Notused
129 VSS Logic Ground
130 - NC Notused
131 - NC Notused
132 VSS Logic Ground
133 - NC Notused
134 SDA EEPROMSerialData
135 VSS Logic Ground
136 SA0 Logic Ground
137 - NC Notused
138 SA1 Logic Ground
139 - NC Notused
140 SA2 Logic Ground
141 VSS Logic Ground
142 SCL EEPROMSerialClock
143 - NC Notused
144 VDDSPD EEPROMPower
