Oki B431L6

7. Connection Diagram
Oki Data CONFIDENTIAL
44983601TH Rev.1
7-14 /
(3) Low-VoltagePower
1
2
1
2
1
11
CN201
CN301
CN101
Acircuit(commonto100Vand200V)forapplyingaloadbetween+5VandGNDtocheckoutputby
usingalow-voltagesupplyunitalone.
Usetheabovementionedjigstocheckoutputbyusingalow-voltagesupplyunitalone.
CN301 6 or 7 pin
CN301 8 or 9 pin
68 , 0.5 W or more
