7. Connection Diagram
Oki Data CONFIDENTIAL
44983601TH Rev.1
7-16 /
7.3 Resistance value
Unit Circuit Diagram and configuration PartDiagram ResistanceValue
DC Motor
BothendsofIP2andIP3:1
or less
Clutch
(Hopping)
(Regist)
(MPTray)
Cable
Cable
Cable Color : Black (Hopping) : Blue (Regist) : Yellow (MP Tray)
1 2
C
BetweenPin1andPin2:240
FuserUnit
Assy
1 2 3 4
Thermostat
Heater
Thermistor
BetweenPin1and2:Several to to several tens of ohms Betweenpin3and4:360K Attheambienttemperature (25ºC)
IP2
IP3
