Oki B431L6

Appendix C Maintenance Manual for Second Tray unit
Oki Data CONFIDENTIAL
44983601TH Rev.1
AppendixC-5/
3.3 How to Replace Parts
This section describes how to replace parts shown in the following disassembling procedure.
In the part replacement procedure, parts on which a part number is displayed in white gure in the
blackcircleareRSPL.
SecondTrayunit Roller-Pick-Up,Roller-Feed-Now(3.3.1)
Guard-Connector,Connector(9715S-08Z02-G4C)(3.3.2)
 Board-GOG(3.3.3)
 CONNCord-AMP8P-AMP8P(3.3.4)
 Gear-Assy-Clutch(Hop,Regist),Motor-Pulse(3.3.5)
 Frame-Assy-Retard,Spring-Retard(3.3.6)
