3.3.1 Roller-Pick-Up,Roller-Feed-Now
(1) Remove Cassette-Assy.
(2) PushthetabinthedirectionofthearrowtoremoveRoller-Pick-Up
.
(3) PushthetabinthedirectionofthearrowtoremoveRoller-Feed-NOW
.
(4) Asforreinstalling,taketheoppositesequencetoremovalsequence.
(Precautions on reinstalling)
1.WhenreinstallingRoller-Pick-Up
,pushituntilitclicks.
 2.WheninstallingRoller-Feed-Now
,pushituntilitclicks.
Tab
②
①
