Oki B431L6

Appendix C Maintenance Manual for Second Tray unit
Oki Data CONFIDENTIAL
44983601TH Rev.1
Appendix C-13 /
4. CleaningofPaperFeedRollerandSeparationRoller
Clean the rollers when [392: Paper Jam] often occurs.
(1) Pull the paper cassette.
(2) Wipethetwofeedrollerswithatightlywrungclothsoakedinwaterthroughtheopeningforinstallation
of a paper cassette.
(3) OpenRetard-Coverofthepapercassetteandwipetheretardrollerwithatightlywrungclothsoakedin
water. (Refer to 3.3.6 for how to open Retard-Cover.)
Feed roller (Roller-Feed-NOW)
Feed roller (Roller-Pick-Up)
Retard roller
Retard-Cover
