Appendix D Network Interface
Oki Data CONFIDENTIAL
44983601TH Rev.1
Appendix D-1 /
Appendix D Network Interface
100BASE-TX / 10BASE-T
(1) Network protocol
TCP/IP: (*: B431 Only)
Network rayer ARP, IP, ICMP, IPv6
Transport rayer TCP, UDP
Apprication rayer LPR, Port9100, FTP, HTTP, HTTPS*, IPP, SNMPv1/v3,
TELNET, DHCP/BOOTP, DNS, DDNS, WINS, UPnP, Bonjour,
SNTP, SMTP, Windows Rally (WSD Print, LLTD), SMB, CIFS
NBT/ NetBEUI:
SMB, NetBIOS, NetBIOS over TCP
NetWare:
Remote Printer mode (Max.8 print server)
Print Server mode (Max.8 file server, 32que)
Encrypted Password (Print Server mode)
NetWare6J/ 5J/ 4.1J (NDS, Bindery)
SNMP
ETHERTALK:
ELAP, AARP, DDP, AEP, NBP, ZIP, RTMP, ATP, PAP
IEEE802.1X: (B431 Only)
EAP-TLS, PEAP
(2) Table of Network I/F signals
Contact No. Signal Name Direction Function
1 TXD+ From Printer transfer data
2 TXD- From Printer transfer data
3 RXD+ To Printer receive data
4 - - don't use
5 - - don't use
6 RXD- To Printer receive data
7 - - don't use
8 - - don't use
