Oki B431L6

Oki Data CONFIDENTIAL
3. Parts replacement
44983601TH Rev.1
3-47 /
-2 Guide-Assy –Eject-U
Note1) Please wipe the amount that grease began to see the sliding area off.
EM-30LP Class C
Apply a normal amount of
MOLYKOTE (EM-30LP)
to flange surface.
EM-30LP Class C
Apply a normal amount of
MOLYKOTE (EM-30LP) to bearing
surface of the shaft.
EM-30LP Class C
Apply a normal amount of
MOLYKOTE (EM-30LP) to bearing
surface of the shaft.
Gear-Exit(Z19)
Bearing-Eject_R
Bearing-Feeder
