Oki B431L6

4. ADJUSTMENT
Oki Data CONFIDENTIAL
44983601TH Rev.1
4-18 /
Unitnamedisplay Drive restriction condition Remarks
MAINMOTOR - -
EXITMOTORFWD FaceUpCoverclose -
EXITMOTORREV FaceUpCoveropen -
REGISTCLUTCH MAINMOTORdriving -
T1HOPCLUTCH MAINMOTORdriving -
MPTHOPCLUTCH(*1) MAINMOTORdriving -
DUPFEEDCLUTCH(*2) MAINMOTORdriving -
T2HOPCLUTCH TRAY2 MOTOR driving OPTION
T2REGISTCLUTCH TRAY2 MOTOR driving OPTION
LVFANTEST - -
FUSERFANTEST - -
IDFANTEST - -
(*1)
B431 only.
(*2)
Noduplexfeedclutchisinstalled.
Note!
Therollersthatrotatecontinuously(each ofheatrollers, imagedrums, andconveyingrollers)
runinsynchronizationwiththemainmotor.
Table 4-4
