Replacing consumable items > 43
8. Place the toner cartridge onto the new image drum cartridge as shown. Push the left
end in first, and then lower the right end in. (It is not necessary to fit a new toner
cartridge at this time unless the remaining toner level is very low.)
Push the coloured release lever (1) away from you to lock the toner cartridge onto
the new image drum unit and release toner into it.
9. Holding the complete assembly by its top centre, lower it into place in the printer,
locating the pegs at each end into their slots in the sides of the printer cavity.
10. Finally, close the top cover.
NOTE
If you need to return or transport your printer for any reason, please make sure
you remove the image drum unit beforehand and place in the bag provided. This
is to avoid toner spillage.
