Loading paper > 15
M
ULTI
PURPOSE
TRAY
1. Open the multi purpose tray (1).
2. Fold out the paper supports (2).
3. Press gently down on the paper platform (3) to ensure it is latched down.
4. Load the paper and adjust the paper guides (4) to the size of paper being used.
> For single-sided printing on A4 headed paper load the paper into the multi
purpose tray with pre-printed side up and left hand edge (LEF), top edge (SEF)
into the printer.
> For two-sided (duplex) printing on A4 headed paper load the paper with pre-
printed side down and left hand edge (LEF), top edge (SEF) away from the
printer. (Optional duplex unit must be installed for this function.)
> Envelopes should be loaded face up with top edge to the left and short edge into
the printer. Do not select duplex printing on envelopes.
> Do not exceed the paper capacity of about 100 sheets or 10 envelopes. Maximum
stacking depth is 10mm.
5. Press the tray latch button (5) inwards to release the paper platform, so that the
paper is lifted and gripped in place.
Set the correct paper size for the multi purpose tray in the Media Menu (see “Menu
Functions”).
2
4
4
3
1
5
