Oki C824 User Manual

- 126 -
7. Maintenance
• Use extra care when handling the image drum (the green cylinder), because it is fragile.
• Image drums are not locked on the printer. They can be removed just by lifting.
6
Turn the toner cartridge lock lever (blue) (6) of the toner cartridge toward you
until its top align on the mark while pressing the toner cartridge.
7
Lift the toner cartridge (7) from the right side, and remove it from the image
drum.
8
Unpack a new image drum and place it on a flat surface.
9
Remove the protective sheet and the desiccant pack.
10
Remove the toner cover.
11
Insert the toner cartridge (7) removed in step 7 by aligning its left side
indentation (8) with the protrusion (9) on the image drum so that the toner

Oki C824 Specifications

General

Monthly Duty Cycle	Up to 75, 000 pages
Duplex Printing	Yes
Printer Type	Color Printer
Connectivity	USB 2.0, Ethernet
Memory	256 MB
Paper Size	A4, A5, B5
Output Capacity	250 sheets
Operating Systems	Windows, macOS, Linux
