Oki C9650n

C9650 User’s Guide> 122
Print Position
Adjust
Duplex X Adjust 0.00
+0.25 – +2.00
-2.00 – -0.25
mm
0.00
+0.01 – +0.08
-0.08 – -0.01in
During the flip-side
printing of duplex
printing, adjusts the
location of the whole
printing image (0.25
mm, 0.01in interval)
perpendicular to the
direction of paper
movement (i.e.
horizontally).
Duplex Y Adjust 0.00
+0.25 – +2.00
-2.00 – -0.25
mm
0.00
+0.01 – +0.08
-0.08 – -0.01
in
During the flip-side
printing of duplex
printing, adjusts the
location of the whole
printing image (0.25
mm, 0.01 in interval)
parallel to the
direction of paper
movement (i.e.
vertically).
Paper Black
Setting
0
+1
+2
-2
-1
Used for fine black
adjustment for a
significantly white
horizontal dotted line,
a significantly faded
image or other such
problem that occurs
in results printed on
plain paper.
Decrement setting
when a white
horizontal dotted line
or a snowing image
occurs in high-
coverage print
portions. Increment
setting when a faded
image occurs.
ITEM VALUE DESCRIPTION
