Oki MC860 Quick Guide

Take control of your color output, document safeguards, and bottom line:
the MC860 MFP from OKI Printing Solutions delivers breathtaking prints
and copies, enhanced security features, and budget-protecting software.
The MC860 MFP from OKI Printing
Solutions delivers brilliant output
at high speeds. It also gives you
control—over the quality of your
output, the degree of your security,
and the extent of your printing
costs. Here are some value-added
examples:
•UniqueHD(HighDenition)Color
technology – For print quality that
visibly enhances your documents,
HD Color technology combines OKI
Printing Solutions multilevel LED
printheads and unique microfine
toner with 1200 x 600 dpi resolution
to provide greater depth of detail
and color, and a high gloss finish,
even on ordinary office paper.
With its standard 40 GB hard disk drive,
the MC860 MFP provides enhanced security
features that include:
Encrypted Secure Print
4
•256-BitEncryption – Enables secure
passage of sensitive documents from PC to
printer, with processing and output requiring
PIN identification.
•JobTimeout – If not
retrieved within a certain
time (pre-set by the user),
the document is sanitized
(cleared) from the hard
disk drive.
•MACValidation – The
Message Authentication
Code (MAC) is encrypted
automatically by the PC
into a document’s printing
data to prevent the file
from being tampered
with after it is sent to the
printer. The printer reads
the code and, if it detects
any alterations to the
file, issues a warning and
cancels the job.
•SecureErase – Ordinarily, simply deleting a
document leaves traces of the contents on
a printer’s hard drive. This feature totally
removes the document from the hard disk
drive, erasing all of the vestiges of a highly
sensitive file or, if desired, sanitizing the
entire disk drive.
Better printer management leads to a better
bottom line. OKI Printing Solutions helps
you with:
•PrintSuperVision – Allows IT support staff
to monitor all business printers within
the firewall, regardless of printer make.
Enables access to networked printer data
for monitoring, reporting and managing
networked printers in real-time. The user
interface is via standard web browsers and
no additional software is required.
•JobAccounting – Enables tracking of
color and monochrome printing costs,
easy monitoring of printing activity, and
greater control of printer usage. It generates
reports for administrative, bill-back or cost-
accounting purposes. User permissions
can be assigned and are stored on the
printer—not on the network—so the system
is totally secure.
Unmatched warranty support – We’re so
confident in the reliable performance of the
MC860 MFP that we provide an industry-
leading 5-year warranty on its printheads. You
can speak to a live expert located in North
America—24/7/365—by calling, toll-free,
800.OKI.DATA (800.654.3282).
3
If you’re looking for a compact, affordable
tabloid multifunction product that will perform
toyouruniquedemands,theMC860MFPfrom
OKI Printing Solutions is exactly what you need.
Without HD Color technology
With HD Color technology
High-capacity toner cartridges: Cyan/Magenta/
Yellow rated at 10,000 pages, Black at 9,500 pages
4
Print and copy speeds at up to 26 ppm
in color, 33 ppm in black & white
2
High reliability: 75,000-page
per month duty cycle
Duplex (2-sided) printing capability
standard
512 MB memory standard; increases to 768 MB max
The MC860 MFP
at a glance:
Storage cabinet comes with
3-Tray Configuration
3-Tray (Floor-standing)
Configuration – Additional
2nd and 3rd 530-sheet trays
expand paper capacity to
max 1,460 sheets
Reversing automatic document feeder (RADF)
handles 50 letter-size sheets or 25 tabloid
sheets; increases user productivity
Flatbed scanner and RADF handle up to
11" x 17" documents
2-Tray (Floor-standing) Configuration –
Additional 530-sheet paper tray
expands paper capacity to 930 sheets
Storage cabinet comes with
2-Tray Configuration
5.8" LCD touch-screen display
300-sheet paper tray standard
100-sheet multi-purpose tray
Wide range of media handling,
including banners up to 47.24"
1-Tray (Desktop) Configuration –
400-sheet capacity
Scan to USB memory via convenient front port

Oki MC860 Specifications

Printing Specifications

print speed color	26 ppm
print speed black & white	33 ppm
time to first page color	10 seconds
time to first page black & white	9.5 seconds
print resolution	1200 x 600 dpi
processor	500 MHz PowerPC CPU
duty cycle	75, 000 prints per month

Copying Specifications

copy speed color	26 cpm
copy speed black & white	33 cpm
first copy out color	14.5 seconds
first copy out black & white	13 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan type	Color and black & white
max scan area	11" x 17"
scan speed black & white	33 spm
scan speed color	26 spm
scan resolution	600 dpi

Fax Specifications

fax modem	33.6 Kbps Super G3
transmission speed	2 seconds/page
fax resolution	600 x 600 dpi
speed dial locations	500 locations
broadcast transmission locations	530 locations

Power and Acoustic Noise

power consumption peak	1, 300W
power consumption standby	160W Avg.
power save mode	≤25W
acoustic noise operating	54dB
acoustic noise standby	≤37dB

System Memory

standard imaging RAM	512 MB
max imaging RAM	768 MB
hard disk drive	40 GB

Weight and Dimensions

1-tray configuration dimensions	22.2" x 25.9" x 26.3"
2-tray configuration dimensions	33.3" x 30.2" x 44.5"
weight 1-tray configuration	149.9 lb
weight 2-tray configuration	200.6 lb
weight 3-tray configuration	211.6 lb
