16
Group Item Settings
Set-Up (cont.) LF Speed Fast, Slow
Width Control Invalid, Mode 1, Mode 2
Parallel I/F I-Prime Invalid, Buffer Print, Buffer Clear
Pin 18 +5V, Open
Auto Feed XT Valid, Invalid
[Epson emulation only]
Bi-Direction Enable, Disable
Serial I/F Parity None, Odd, Even
# Serial Bits 8 Bits, 7 Bits
Protocol Ready/Busy, X-ON/X-OFF
Diagnostic Test No, Yes
Busy Line SSD-, SSD+, DTR, RTS
Baud Rate 9600 BPS, 4800 BPS, 2400 BPS, 1200 BPS,
600 BPS, 300 BPS, 19200 BPS, 38400 BPS
DSR Signal Valid, Invalid
DTR Signal Rdy on Pwr Up, Ready on Select
Busy Time 200 ms, 1 sec
