Oki OkiLAN 6120e - Setting up the Okilan 6120 E for Public Access Printers at the File Server Console

III - 37
Section 3 - Chapter 4 - Using the OkiLAN 6120e in NDPS
OKI OkiLAN 6120e User’s Guide
NetWare
Setting Up the OkiLAN 6120e for Public Access
Printers At the File Server Console
1. Create NDPS Manager in NWAdmin32.
2. Load the NDPS Manager on the file server.
3. Select Insert New Printer Agent.
4. Give the Agent a Name.
5. Go to Configuration Utilities.
6. Select Novell Printer Gateway.
7. Select Appropriate Printer.
8. Select Novell Port Handler.
9. Select Remote Printer: LPR/TCPIP.
10. From the OkiLAN 6120e Configuration Sheet, get the
print servers IP address. Click <Enter> at IP Host, then
enter IP address of print server.
11. The LPR Printer Name is the output port of the print
server.
12. Click Accept and Exit, then use Escape key to save.
