57
R-1
Group Item Settings
Set-Up (continued) Operator Panel Function
Full Operation , Limited Operation
Print Registration 0 , 0.05 mm Left, 0.10 mm Left,
0.15 mm Left, 0.20 mm Left,
0.25 mm Left, 0.25 mm Right,
0.20 mm Right, 0.15 mm Right,
0.10 mm Right, 0.05 mm Right
Reset Inhibit
No , Yes
Print Suppress Effective Yes , No
Auto LF
No , Yes
Auto CR (appears only when IBM
Proprinter emulation is selected)
No , Yes
SI Select Pitch, 10 cpi (appears only
when IBM Proprinter emulation is
selected)
17.1 CPI , 15 CPI
SI Select Pitch, 12 cpi (appears only
when IBM Proprinter emulation is
selected)
20 CPI , 12 CPI
Time Out Print
Valid , Invalid
Auto Select
No , Yes
Ribbon Selection (Optional color
ribbon must be installed in order to
print in colors other than black)
Black Ribbon , Black, Yellow,
Magenta, Cyan, Violet, Orange,
Green
Printhead Gap Adjust 0 , -1, +1
Graphics Speed High,
Low
Parallel I/F I-Prime Buffer Print, Buffer Clear, Invalid
Pin 18
+5v , Open
Auto Feed XT (appears only when
Epson LQ emulation is selected)
Invalid , Valid
Serial I/F (appears only when
optional Serial Interface is installed)
Parity
Serial Data 7/8 Bits
None , Odd, Even
8 Bits , 7 Bits
Protocol
Ready/Busy , X-On/X-Off
Diagnostic Test
No , Yes
Baud Rate 19200 bps,
9600 bps , 4800 bps,
2400 bps, 1200 bps, 600 bps, 300
bps
Busy Line SSD -, SSD+, DTR, RTS
DSR Signal
Valid , Invalid
DTR Signal
Ready on Power Up , Ready on
Select
Busy Time 200 ms , 1 sec
CSF Bin 1 (appears only with
optional Cut Sheet Feeder installed)
Line Spacing
6 LPI , 8 LPI
Bottom Margin
Valid , Invalid
Page Width (Model 591 only)
13.6” , 8.5”
Page Length
11” , 11-2/3”, 12”, 14”, 17”, 3”,
3.5”, 4”, 5.5”, 6”, 7”, 8”, 8.5”
Gap Control Auto Gap , Semi Auto Gap, 1, 2, 3,
4, 5, 6, 7, 8, 9
