1308S20022 10-4
PARTS LIST CONTINUED
ITEM NO PART DESCRIPTION PART NUMBER______QTY
314 Bar-Pusher 1308-0057 1
315 Bolt-Carriage ½-13 x 4-1/2” 5804-1722 1
316 NUT-ACORN STD 1/2"-13 5831-8100 1
317 NUT-HEX FULL 1/2-13 5832-0524 2
318 WASHER-1/2" SPRING LOCK 5851-9011 1
319 WASHER-7/16" FLAT 5851-9307 1
320 Box-Relief 1308-0059 1
321 Bushing-Strain Relief 5765-1110 2
322 Nut-Hex Head Lock (PG-11) 5766-7786 2
323 SCREW-ROUND HD 6-32 5843-5210 4
325 SCREW-HEX HD 1/4-20 5843-1005 2
326 WASHER-LOCK 1/4" 5851-9357 2
327 Enclosure-Electrical 1308-0060-2 1
329 Brace-Ground 1308-0062 1
333 INLET-POWER-1 POLE W/SWITCH 5746-7902 1
333 Inlet-Fused Power w/ Switch (2 pole) 5746-7901 1
334* Fuse-5 x 20 mm (4Amp) 5725-9571 1
334* Fuse-5 x 20 mm 230V 5725-9500 1
336 SCREW-ROUND HD 4-40 5843-5190 2
337 NUT-HEX MACHINE #10-24 5832-0578 2
338 SCREW-SLTD TRSHD MACH 10-24 5843-5389 2
* Item Not Shown Bold items are required for 120V North American sale
Rev 8-15-09
