MODEL 702-N, 702-NSE and 702-NSS BUN SLICERS
0702S20035-1
ADJUSTMENTS
WARNING
NEVER ATTEMPT TO ADJUST OR SERVICE THIS MACHINE UNTIL
YOU ARE SURE THE BLADE HAS STOPPED.
OUTSIDE SIDE GUIDE
This guide is used to determine the amount of "Hinge" left on the product and can be
adjusted from leaving approximately a 1/2" hinge to a complete sever.
The guide is adjusted by loosening the two knobs which are below and to the outside of
the table and by sliding the guide in or out to generate the desired amount of hinge. Re-
tighten the knobs when the guide is in the desired location.
CAUTION
MAKE SURE THAT THE BLADE IS NOT HITTING ANY OF THE OTHER
COMPONENTS BEFORE RE-STARTING THE MACHINE.
TABLE HEIGHT ADJUSTMENT
The table can be adjusted so that the height of the blade above the table is between 5/8"
and 1-1/2".
To change the height of the blade loosen the large knob on the front corner of the
machine's base below the table. Once loosened the thumb screw below the table can
be rotated clockwise to increase the table height (decrease bottom slice thickness),
or rotated counter clockwise to decrease table height, (increase bottom slice thickness).
Once the desired slice thickness is achieved re-tighten the large knob on the corner of
the base to secure the table in the new position.
CAUTION
MAKE SURE THAT THE BLADE IS NOT HITTING ANY OF THE OTHER
COMPONENTS BEFORE RE-STARTING THE MACHINE.
INSIDE SIDE GUIDE
Generally it is best to leave the inside guide adjusted to the maximum opening, this will
allow the product to pass through uninhibited for maximum slicing speed. However,
some products will require its use to reduce jamming.
(continued on next page)
