Oliver 797-32NC - Page 3

797-N BREAD SLICER
0797S20020 0-2
INDEX (Continued)
REPLACEMENT PARTS SECTION (Continued)
Section Description
Document No. Page No.
SLICE PARTS & HOLDDOWN ------------------------------- 0797S20030 -------------------------- 10-1
Drawing ----------------------------------------------------------------------------------------------- 10-1
Parts List ---------------------------------------------------------------------------------------------- 10-2
32 INCH GRAVITY INFEED CHUTE ------------------------ 0797S20031 -------------------------- 11-1
Drawing ----------------------------------------------------------------------------------------------- 11-1
Parts List ---------------------------------------------------------------------------------------------- 11-2
48 INCH GRAVITY INFEED CHUTE ------------------------ 0797S20032 -------------------------- 12-1
Drawing ----------------------------------------------------------------------------------------------- 12-1
Parts List ---------------------------------------------------------------------------------------------- 12-2
32 INCH COMBINATION INFEED CHUTE ---------------- 0797S20058 -------------------------- 13-1
Drawing ----------------------------------------------------------------------------------------------- 13-1
Parts List ---------------------------------------------------------------------------------------------- 13-2
STANDARD OUTFEED ---------------------------------------- 0797S20033 -------------------------- 14-1
Drawing ----------------------------------------------------------------------------------------------- 14-1
Parts List ---------------------------------------------------------------------------------------------- 14-2
DRIVEN PULLEY ------------------------------------------------ 0797S20034 -------------------------- 15-1
Drawing ----------------------------------------------------------------------------------------------- 15-1
Parts List ---------------------------------------------------------------------------------------------- 15-2
SINGLE PHASE ELECTRICAL ------------------------------- 0797S20035 -------------------------- 16-1
Wiring Diagram --------------------------------------------------------------------------------------16-1
Drawing ----------------------------------------------------------------------------------------------- 16-1
Parts Lists -------------------------------------------------------------------------------------------- 16-2
THREE PHASE ELECTRICAL ------------------------------- 0797S20036 ------------------------- 17-1
Wiring Diagram ------------------------------------------------------------------------------------- 17-1
Drawing ----------------------------------------------------------------------------------------------- 17-1
Parts Lists -------------------------------------------------------------------------------------------- 17-2
WARRANTY ------------------------------------------------------- GEN 040228
WARRANTY PROCEDURE ----------------------------------- GEN 040226
RETURNED PARTS POLICY -------------------------------- GEN 040227
REV. 3/2/04
