Olsen BML-60BRBU2 - Parts Listing: Chimney Vent Models BML80(B2,BRF2) and BMLV80(B2,BRF2)

28
P/N 30149, Rev. G [12/15/2016]
Parts Listing: Chimney Vent Models BML80(B2,BRF2) and BMLV80(B2,BRF2)
Ref. No. Description Part No.
1 Left Side Panel Assembly 29631AD
2 Right Side Panel Assembly 29630AD
3 Rear Panel 29638AD
4 Blower Division Assembly 29676
5 Base Panel Assembly 28459
6 Inner Front Panel 30154
7 Blower Access Panel 27367AD
8
Front Door Panel 30157AD
Logo Bezel 28479
Logo Label 28563
9 Top Front Panel 26017AD
10 Heat Exchanger Assembly 550001635
11 Firepot Bracket Assembly 27068
12 Replacement Combustion Chamber 27000WP
13 Bafe 30152
14
Clean-out Gasket Retainer (2 per unit) 29161
Clean-out Gasket (2 per unit) 29163
15 Pouch Gasket 2080175
16
Oil Burner Mounting Plate Assembly
109007674
Oil Burner Mounting Plate
109007675
Sight Glass Cover Plate
29850
Sight Glass Gasket (2 per unit)
29870
Sight Glass
29876
17 Flue Pipe Collar 27476
18 Air Filter - 20 x 20 x 1 (Permanent) 2180032
19 Control Panel 30010
20 Control Panel Cover 29654
21
Wire Harness Blower Motor Direct Drive 29690
Wire Harness Blower Motor Belt Drive 29691
22 Wire Harness Fan Timer Board Chimney Vent 29364
23 Wire Harness Transformer and Supply 29751
24
Fan Timer Control 1158-120 UTEC
29388
Fan Timer Control 1168-1 ECM UTEC 240007048
25 Transformer, 120/24V, 40a 240005330
26 Limit Control 60T11 (L260°F) BOF (Black Oxide Finish) 30153
27 Draft Regulator 27494
28
Beckett AF Oil Burner Assembly, Beckett AF76BNHS 30067
Burner Motor 1/7 HP 3450 RPM PSC 29689
Oil Pump, Clean-Cut A2EA6520 29688
Solid State Ignitor 29522
Oil Primary Combustion Control 7505P1515 240008818
Flame Retention Head 1050002
Low Fire Kit 29880
Low Firing Rate Bafe 25521101
Oil Burner, Riello 40F3 29568
PARTS LISTING
