2.0 PRODUCT INFORMATION
CLEARANCE (minimum) TO COMBUSTIBLES
Top of Supply Plenum 1” (25 mm)
Front (Maintenance) 36” (915 mm)
Rear 1” (25 mm)
Side – Non-Access 1” (25 mm)
Side – Access maintenance 24” (610 mm)
Flue Pipe 9” (229 mm)

DRAFT PRESSURE
Breech draft pressure -0.01” WC minimum
BURNER TUBE INSERTION
HTL-100 6-3/8" (162 mm)
HTL-200 9-1/2" (240 mm)

 
  
      
  

HTL-100 1/2 hp 4 Speed PSC / G10-8 DD or 1/2 hp 5 speed ECM / G10-8 DD
HTL-200 3/4 hp 4 Speed PSC / GT12-10 DD or 3/4 hp ECM 5 speed / GT12-10 DD

United Technologies 1158-120 Fan Center & Thermo-Disk (7” stem)
FLUE-PIPE CONNECTION

CLEANOUTS

THERMOSTAT
Any wall thermostat
Thermostat adjustment as per thermostat manufacturer installation.
