RESET
ZONE 01
The setting ‘1=ACTIVE’ blinks. If the ’2’ key is pressed then the selected
zone is reset and the setting ‘2=RESET’ starts to blink. Pressing ‘1’ again
will reactivate the zone.
ZONE 01
1=ACTIVE 2=RESET
With the numeric keypad we select the required
zone and after pressing ‘ENTER’ we see :
TEST MODE
ALARM RELAY 1
The setting ‘2=DEACTIVE’ blinks. If the ‘1’ key is pressed then the relay is
activated and the setting ‘1=ACTIVE’ starts to blink. To deactivate the
relay press the ‘ 2’ key.
ALARM RELAY 1
1=ON 2=OFF
Select the ALARM relay on the required panel and
press ‘ENTER’. The Display shows:
TEST MODE
FAULT RELAY 1
The setting ‘2=DEACTIVE ’ blinks. If the ‘1’ key is pressed then the relay
is activated and the setting ‘1=ACTIVE’ starts to blink. To deactivate the
relay press the ‘2’ key.
FAULT RELAY 1
1= ON 2=OFF
Select the FAULT relay on the required panel and
press ‘ENTER’. The Display shows:
TEST MODE
SIREN 1
The setting ‘2=DEACTIVE’ blinks. If the ‘1’ key is pressed then the output is
activated and the setting‘1=ACTIVE’ starts to blink. To deactivate the
output press the ‘2’ key.
SIREN 1
1=ON 2=OFF
Select the required siren output and press ‘ENTER’.
The Display shows:
TEST MODE
24V-MON ->PANEL 1
The setting blinks . If the ‘2’ key is pressed then the output is
deactivated and the setting ‘2=DEACTIVATE’ starts to blink. To reactivate
the output press the ‘1’ key.
‘1=ACTIVE’
24V-MON ->PANEL 1
1=ON 2=OFF
Select the output on the required panel and press
‘ENTER’ the Display shows:
The setting blinks. If the ‘1’ key is pressed then the relay is
activated and the setting ‘1=ACTIVE’ starts to blink. In order to deactivate
the relay press the ‘2’ key. If a BS-117 relay module is not connected to the
‘2=DEACTIVE’
REMOTE RELAY 01
1=ON 2=OFF
Select the required zone relay and press
‘ENTER’. The Display shows:
UNIT IS
NOT CONNECTED
system then this operation is not available and the
system displays the message:
TEST MODE
RELAY (1/64) 01
13 from 21
921116000
Date
File
Code
Page
921116000_09_016
13/03/2013
