CONTENTS
1. INTRODUCTION
2. PART TYPES
3. COMPOSING A COMPLETE SYSTEM.
3.1. Systems up-to 48 zones-rooms.
3.2. Systems from 49 to 240 zones -rooms.
3.3. System with many keyboards (repeaters).
4 DESCRIPTION OF KEYS AND INDICATIONS.
5. ACCESS CODES
6. PROGRAMMING
6.1. PRO. Rooms - Zones programming.
6.2. SETUP. Option settings
6.2.1 Address
6.2.2. CLr?.
6.2.3. buzz
6.2.4. UCod.
6.2.5. Ccod
6.2.6. UsuP
6.2.7. dLoA
6.2.8. r-AL
6.3 TEST
7. SIGNAL NUMERATOR PANEL OPERATION MODE (OPERATING).
7.1. Start position operation.
7.2. Calling from one call point.
7.3. Calling from more than one call points.
7.4. Resetting indications - calls.
7.5. Resetting all the calls with a code.
7.6. Viewing the communication faults and the software version of
the keyboard.
7.7. Fault indication signals.
8 PRESENCE OPERATION MODE.
9. USEFUL INSTRUCTION FOR FAST AND EASY MOUNTING.
Instruction flow chart for fast and easy installations.
Page 2 from 18
921746000_09_003
