6.2.4 Ucod.
Changing the technical code (1111=default)
Insert the technical code (1111) and using the key FAULT EVENTS scroll to the
indication S-UP. Press ENTER and scroll to the Ucod indication using the arrow keys.
When the ENTER key is pressed the indication 1111 is shown on the display.
(This means that this keyboard has a programming - technical code of 1111).
If we want to change the code press the new four digit number (e.g. 1974) and
press the ENTER key, so as to accept the new four digit number.
At the end of the process press successively the ESC key to exit programming
mode.
Page 9 from 18
6.2.3 buzz.
Buzzer sound mode and mode operation system.
With this programming operation we can change the sound mode of the buzzer
when there is a call. Insert the technical code (1111) and using the key FAULT
EVENTS scroll to the indication S-UP, press the ENTER key and scroll to the
indication buzz using the arrow keys. Then press the ENTER key and the display
shows the indication _ _ _ 1. (This means that the buzzers sound mode is 1 ).
The table below explains the different sound mode that are available.
VALUE PROGRAMMING
Buzzer deactivated - Signal numerator panel operation mode
(default) 5 short sounds - Signal numerator panel operation mode
1 long sound - Signal numerator panel operation mode
3 continuous sounds - Signal numerator panel operation mode
Buzzer deactivated - Presence indication operation mode
If we want to change this value, press the required number (0 to 4)and then
press ENTER so the keyboard can accept the new value. At the end of the process
press successively the ESC key to exit programming mode.
If we give the value of 4, the buzzer will not sound. This sound mode is used only
when the system is configured to operate in Presence indication mode.
(See section 8).
921746000_09_003
