16
The cutting mechanism runs in reverse and pushes the paper back out.
Remove the paper and reduce the quantity of paper being fed in.
Move the sliding switch back to Auto.
Continue with the shredding process.
If the jam is not cleared by the reverse/forward running process, disconnect the power
plug and remove the remaining material from the cutting mechanism manually.
Motor Protection
The motor switches off automatically in the event of an overload. Disconnect the power
plug from the power socket and let the motor cool down for 30 to 40 minutes to room
temperature. Then connect the power plug to the power socket again and continue op-
eration.
Maintenance and Service
Caution: maintenance work may only be performed when the mains plug is
pulled out.
Clean the housing with a slightly moist cloth.
Do not use any aggressive cleaning agents. Never use any chemicals (e.g. cleaning
solvent, alcohol) to clean the housing.
To ensure your shredder enjoys a long working life, we recommend to clear residual ma-
terial from the cutting units at regular intervals and apply special oil for paper shredders
to the cutting unit. You can purchase a special CFC-free oil from your specialist retailer or
directly from our Service Center in Hattingen. This will extend the service life of the de-
vice.
Attention: It is forbidden to use oil spray bottles containing CFC!
Technical Data
Model: PS 33T
Feed capacity: Max. 5 sheets A4 (80 g/m²)
Working width of paper infeed: 217 mm
Strip size: 6 mm
Waste bin volume: 7 litres
Cutting speed: 2,5 - 3,0 m/min
Noise level: 73 dB
Operating cycle, paper: 2 min on, 40 min off
Power supply: 220-240 V / 50 Hz
Max. power consumption: 0.5 A (190 VA)
Dimensions (W x D x H): 315 x 148 x 228 mm
Weight: 1.215 kg
