Contents
1 Sample holders for the OLYMPUS CIX100 Cleanliness Inspector System 4
1.1 Introduction 4
1.2 Intended use 4
1.3 About these instructions 4
1.4 Available sample holders and sample types 5
2 Safety 9
2.1 Symbols and safety instructions 9
3 Setup of OLYMPUS CIX100 Cleanliness Inspector System at time of delivery 12
4 Adding new sample types to your CIX100 system 13
5 Calibrating Shading Correction for a new sample type 15
6 Calibrating White Balance for a new sample type 24
7 Performing an inspection with different sample types with a CIX100 system 33
8 Best Practices for the versatile sample holders for your CIX100 system 36
8.1 Mounting and inspection of filter membranes in the CIX100 system 36
8.2 Mounting and inspection of tape lift samples in the CIX100 system 38
8.3 Mounting and inspection of particle trap samples in the CIX100 system 41
9 Exchanging the stage insert of a CIX100 system for metallurgical applications 45
- 3 -
