4. Nomenclature
4-1. Front panel
PRODUCT SPECIFICATIONS
1. Power switch
Push the right side to turn on the unit. The switch lamp lights and the illumination lamp
(halogen) lights up.
2. Output connector
Supplies an illumination light to the scope and light guide cable connected.
3. Brightness control
Turn clockwise to increase brightness and counterclockwise to darken.
4-2. Rear panel
1. Fuse box
Contains the fuse to prevent a fire due to the light source or other danger when en error occurs.
2. Inlet
Connects the power cord.
1-4
1. Power switch
2. Output connector
3. Brightness control
1. Fuse box
2. Inlet
