Olympus Delta User Manual

103158-01EN [U8998465], Rev. A, April 2012
2 Product Overview
• Read the Important Information section carefully before handling this product.
• Refer to the DELTA User’s Manual (P/N: 103201) for more detailed information.
1. Product Overview
The DELTA Portable Workstation provides a fully shielded, rugged test stand for benchtop or remote-controlled testing. It
is comprised of:
• An A020-D test stand (U8990865)
• Any DELTA handheld analyzer model (including the Premium, Standard, or Classic)
In this configuration, the DELTA is controlled by the Olympus DELTA PC software. The open-beam handheld analyzer is
then converted into a safe closed-beam workstation.
1.1 Test stand
CONTENTS
“Product Overview” ..................................................................................................................................................................Page 2
“Safety Information” ................................................................................................................................................................Page 3
“Physical Planning” ..................................................................................................................................................................Page 5
“Unfolding the Test Stand” .....................................................................................................................................................Page 6
“Configuring the Workstation” ..............................................................................................................................................Page 8
“Important Information — Please Read Before Use”.......................................................................................................Page 11
Component Key DELTA Portable Workstation — All models
1 Hinged lid
2 Test chamber
3Locking levers
4Hinged leg
1
2
3
4
3
4
