Olympus E-1 Basic Manual

Olympus E-1
180 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Page #5 background imageLoading...
Page #5 background image
5
En
Getting Started
External flash
connector
BKT (Auto bracket)
button
(Metering) button
DRIVE button
Focus mode
lever
DC-IN jack
Connector cover
IEEE 1394 connector
Eject button
Card cover
Card slot
USB connector
VIDEO OUT jack
Remote cable
connector
Strap eyelet
Eyepiece shutter lever
Viewfinder
Diopter adjustment dial
AEL
buttonMain dial
(AF frame
selection) button
Card access
lamp
Card cover lock
OK
button
Arrow pad
(Menu) button
(Playback
mode) button
Monitor
(A monitor cover is
attached.)
(Erase) button
(Protect) button
INFO
(Information
display) button
1 E-1 Ba-EN P1 03.7.8 5:55 PM Page 5

Table of Contents

Other manuals for Olympus E-1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Olympus E-1 and is the answer not in the manual?

Olympus E-1 Specifications

General IconGeneral
Max Resolution2560 x 1920
Image Ratio w:h4:3
Sensor TypeCCD
Lens MountFour Thirds
Focal Length Multiplier2x
White Balance Presets6
Digital ZoomNo
Image StabilizationNo
RAW FormatYes
Shutter PriorityYes
Aperture PriorityYes
Manual Exposure ModeYes
Built-in FlashNo
Flash X Sync Speed1/180 sec
Viewfinder TypeOptical (pentaprism)
LCD Screen Size1.8"
Screen Dots134, 000
Shutter Speed60 - 1/4000 sec
Continuous Shooting3 fps
Storage TypeCompactFlash (Type I or II), Microdrive
USBUSB 1.1
Dimensions141 x 104 x 81 mm (5.55 x 4.09 x 3.19 in)
Camera TypeSLR
Effective Pixels5.0 MP
Sensor Size17.3 x 13.0 mm
Metering ModesCenter-weighted, Spot
Exposure Compensation±3 EV (1/3 EV steps)
External FlashYes
Drive ModeSingle, Continuous, Self-timer
Self-timerYes (12 sec, 2 sec)
BatteryLithium-Ion
Weight660 g (1.46 lb)
ISO Range100-800 (expandable to 1600, 3200)
