Chapter 3 Cleaning, Disinfection and Sterilization Procedures
17
EVIS EXERA GIF/CF/PCF TYPE 160 Series REPROCESSING MANUAL
Water-resistant cap (MAJ-942 for CF-Q160DL/I only)
The water-resistant cap (MAJ-942) is attached to the UPD scope connector on
the endoscope to protect the connector from water penetration during
reprocessing. The water-resistant cap is connected to the endoscope by a chain
(see Figure 3.4).
Figure 3.4
Channel plug (MH-944)
The channel plug is used to plug the openings of the instrument channel port,
air/water and suction cylinders during cleaning (see Figure 3.5).
Figure 3.5
