Olympus LS-14 User Manual

Identification of parts
1 Built-in stereo microphone
2 Built-in center microphone
(LS-14 only)
3
MIC (Microphone) jack
4
LINE IN jack
5 Card cover
6
STOP / w ( 4 ) button
File screen (C):
1 Current file name
2 Battery indicator
3 [OVERdub] indicator, Metronome
indicator, Folder name
4 Recorder status indicator
[ H REC ]: Record indicator
[ G PAUSE ]: Pause indicator
[ F STOP ]: Stop indicator
[ E PLAY ]: Play indicator
[ I FF ]: Forwarding indicator
[ J REW ]: Rewinding indicator
[ X F.PLAY ]: F. Play indicator
[ Y S.PLAY ]: S. Play indicator
5 Remaining memory bar indicator,
Playback position bar indicator
6 Level meter
7 Function guide indicator
8 Remaining recording time,
File length
9 Elapsed recording time,
Elapsed playback time
s
Do not leave the battery within the
reach of infants or children.
They could swallow the battery. If
this happens, immediately consult
a doctor.
s
If you notice an abnormality such as
abnormal sound, abnormally high
temperature, burnt odor or smoke
during use, perform the following
steps:
1 Immediately remove the battery
carefully.
2 Contact your dealer or the
Olympus Service Station for
service. Leaving it could cause a
fire or burn.
s
Do not soak the battery in freshwater
or seawater or let the terminals get
wet.
s
If a battery leaks, becomes discolored
or deformed, or becomes abnormal
in any other way during operation,
stop using the recorder.
s
If a battery leaks fluid onto your
clothing or skin, remove the
clothing and flush the affected
area with clean, cold running water
immediately. If the fluid burns
your skin, seek medical attention
immediately.
f Caution:
s
Do not apply a strong shock to the
battery or throw it.
s
Please recycle batteries to help
save our planet’s resources. When
disposing of dead batteries, be sure
to cover their terminals and always
observe local laws and regulations.
Inserting batteries (Fig. 1)
This recorder can be used with AA
Alkaline Batteries.
1 Press the battery cover release
button, and then slide the battery
cover open while lightly pressing it
down.
2 Insert the batteries, observing the
correct = and - polarities.
3 Close the battery cover completely
by pushing the cover downwards
in direction A while sliding it in
direction B .
7
REC ( s ) (Record) button,
Recording indicator light (LED)
8
MENU button
9 Mode dial
0
PEAK indicator light (LED)
! LED indicator light
@ Display (LCD panel)
#
F1 button, F2 button, F3 button
$
PLAY ( ` ) button
%
+ button
^ 0 button
&
OK button
*
ERASE button
(
– button
) 9 button
- Battery cover
= Battery cover release button
q Tripod socket
w Built-in speaker
e
EAR (Earphone) jack
r
REMOTE jack
Connect the receiver of the
exclusive remote control set
RS30W (optional). This enables
operation of the start and stop
recording functions through the
remote control.
t USB connector
y
POWER/HOLD switch
u Strap hole
Display (LCD panel)
Folder list screen (A):
1 Total number of recorded files in the
folder
2 Battery indicator
3 Folder name
4 Function guide indicator
File list screen (B):
1 Current folder name
2 Battery indicator
3 File name
4 Function guide indicator
EN EN EN EN EN EN EN EN EN EN EN EN EN EN
7
EN EN

Olympus LS-14 Specifications

General

Recording modes	Pulse-code modulation (PCM)
Built-in microphone	Yes
Maximum recording time	46 h
Audio formats supported	MP3, WAV
FM radio	-
Interface	USB
Media types supported	Internal memory & flash card
Compatible memory cards	SD, SDHC
Built-in memory capacity	4 GB
Product color	Black
Languages support	CZE, DAN, DEU, ENG, ESP, FRE, ITA, POL, RUS
Audio recording formats	MP3, PCM
Weight (including battery)	170 g
Number of built-in speakers	3
Compatible battery sizes	AA
Number of batteries supported	2

Weight and Dimensions

Depth	23.5 mm
Width	52.5 mm
Height	138.7 mm
