Olympus LS-P1 - Specifications

7
Specifications
119
EN
General items
4 Recording formats
Linear PCM format
MP3 format
4 Input level
– 60 dBv
4 Sampling frequency
Linear PCM format
96.0 kHz/24 bits 96.0 kHz
88.2 kHz/24 bits 88.2 kHz
48.0 kHz/16 bits 48.0 kHz
44.1 kHz/16 bits 44.1 kHz
44.1 kHz mono 44.1 kHz
MP3 format
320 kbps 44.1 kHz
128 kbps 44.1 kHz
64 kbps mono 44.1 kHz
4 Maximum working output
150 mW (8 Ω speaker)
4 Maximum output voltage
Recorder: â 150 mV
(according to EN 50332-2)
4 Recording media*
Internal NAND flash memory:
LS-P2:
8GB
LS-P1: 4 GB
microSD card
(Supports card capacities ranging from
2 to 32 GB.)
* Some recording media memory
capacity is used as a management
area, so the actual usable capacity
will always be slightly less than the
displayed capacity.
4 Bluetooth Specification*
1
Standard: Version 2.1+ EDR Support
Transmit Power Level: Class2
Communication Distance:
Line of sight approx. 10 m*
2
(max.)
Operational Frequency Range:
2.4 GHz to 2.4835 GHz
Modulation Method: FHSS
Compatible Profiles:
A2DP (Advanced Audio Distribution
Profile)
AVRCP (Audio/Video Remote Control
Profile)
HSP (Headset Profile)
HFP (Handsfree Profile)
SPP (Serial Port Profile)
*1 LS-P2 model only
*2 The communication distance is
guideline values. The communication
distance may vary depending on
ambient conditions.
4 Speaker
Built-in 18 mm diameter round dynamic
speaker
4 Microphone jack
3.5 mm diameter; Impedance: 2 kΩ
4 Earphones jack
3.5 mm diameter; Impedance: 8 Ω
minimum
4 Power source
Standard voltage: 1.5 V
Battery: One AAA dry cell battery (model
LR03), or one Olympus nickel-metal
hydride rechargeable battery
External power supply: USB-connection
AC adapter (model A514; 5 VDC)
Specifications
