Olympus OME-V200 - Page 2

– 2 –
4 Unpacking
1 Cut and remove the ester bands (× 3) by the nipper.
CAUTION
Be careful not to cut your hand when cutting the ester band.
2 Remove the cap.
Figure 3
NOTE
The removed cap will later be used as a slope.
3 Cut the tape of (four corners of) the pallet by the cutter.
Figure 4
Figure 2
Ester bands (× 3)
Cap
Pallet
