4 Remove metallic fasteners (× 16) by phillips screwdriver.
Figure 5
5 While holding the sleeves so that the sleeves will not collapse,
remove the sleeves (× 2).
6 Pull and remove the pads (× 8).
7 Remove the BI pad.
Figure 7
Metallic fasteners
Sleeve
Figure 6
Front Rear
Pads Pads
BI pad
