Olympus u DIGITAL 800 - Charging the Battery; Inserting the Battery

5
En
CHARGING THE BATTERY
Battery charger
Power cable
AC wall
outlet
Lithium ion battery
Charging indicator
Lit red: Charging
Lit green: Charging complete
(Charging time: Approx. 120 minutes)
INSERTING THE BATTERY
Battery lock knob
To remove the
battery
2
1
3
4
5
