OMA 502 - Vehicle Weight and Size; Vehicle Dimensions and Clearance; Vehicle Weight Limits

Fig.11-Abb.11
Fig.12-Abb.12
TIPIDIVEICOLISOLLEVABILIEINGOMBRI
Ilsollevatoresiadattapraticamenteatuttiiveicolidipesononsuperio
-
rea2800Kgelecuidimensioninoneccedanoquelleriportatedisegui
-
to.
DIMENSIONIMASSIMEDEIVEICOLIDASOLLEVAREFig.11
Lalarghezzanondeveeccederei2200mm.
Ilpassotragliassinondeveeccederei3000mm.
L’altezzaminimadaterrapuòinterferireconlestrutturedelsollevatore.
Fareattenzionesoprattuttoalleautovetturesportive.
Eventualicarrozzatispecialipossonoesseresollevatitenendoperò
contodellaportatadelsollevatore.
Anchelazonadisicurezzaperlepersonedovràessereadeguata
alledimensionispecialidelveicolo.
Glischemiseguentiriportanoicriteriperdefinireilimitidiimpiegodel
sollevatore.
PERINGOMBRIMAGGIORIVERIFICAREILCARICOMASSIMOE
LOSBILANCIAMENTODELCARICO.
PESIMASSIMIDEIVEICOLIDASOLLEVAREFig.12
VEHICLEWEIGHTANDSIZE
Liftrackcanbeadaptedtovirtuallyallvehiclesnoheavierthan2800kg,
thedimensionsofwhichdonotexceedthefollowing.
MAXIMUMDIMENSIONSOFVEHICLESTOBELIFTEDFig.11
Max.width:2,200mm.
Max.wheelbase:3000mm.
Theunderbodyofcarswithlowgroundclearancemayinterferewiththe
structureofthelift.Payparticularattentioninthecaseoflowbody
sportscars.
Alwayskeepthecapacityoftheliftinmindinthecaseofvehicleswith
particularcharacteristics.
Thesafetyareawillbedeterminedbythedimensionsofthevehic
-
le.
Thediagramsbelowincludethecriteriafordefiningthelimitsofuseof
thecarrack.
CHECKMAXIMUMLOADCAPACITYANDLOADDISTRIBUTIONIN
THECASEOFLARGERVEHICLES.
MAXIMUMWEIGHTOFTHEVEHICLETOBELIFTFig.12
18
Min.(mm) Max.(mm)
A
—- 2200
B
—- 3000
C
150 —-
A
B
C
I
MAX.2800Kg.!
1650
1150
1150
1650
