Omax M82ES Series User Manual

www.microscopenet.com
- 8 -
4 Specifications
General
Model
M82ES series
Total Magnification
40X, 80X, 100X, 200X, 400X, 800X, 1000X, 2000X
Viewing Head
Binocular, inclined 45º, swiveling 360º
Interpupillary Distance
Sliding adjustment, 2-3/16” ~ 2-15/16” (55mm ~ 75mm)
Diopter Adjustment
On both eyepiece tubes
Eyepieces
1 pair of wild field WF10X/18
1 pair of wild field WF20X
Nosepiece
Revolving quadruple
Objectives
Achromatic DIN 4X/0.10 160/0.17
10X/0.25 160/0.17
40X/0.65 160/0.17(spring),
100X/1.25 160/0.17(spring, oil)
Condenser
Abbe, NA=1.25, w/ iris diaphragm
Rack and pinion adjustment
Focus Mechanism
Coaxial coarse and fine focusing knobs on both sides
with rack stop
Mechanical Stage
Double layer, dimension: 4-1/2" x 4-15/16" (115mm x 125mm)
X-Y translational range: 2-13/16” x 1-3/16” (70 mm x 30 mm)
Illumination
Transmitted, LED, variable intensity
Camera (optional)
Refer to the cameras specifications
Dry Darkfield Condensers (optional)
Refer to the Dry Darkfield Condensers Installation &
Operation Instruction
Power Supply
AC/DC adapter, 7.5V/7.5W (UL approved)
- Input: 100-240VAC, 50/60Hz, 0.5A Max
- Output: DC7.5V, 1000mA
Dimension
9-1/16” x 7-1/8” x 13” (23cm x 18cm x 33cm)
Net weight
7 lbs 2 oz (3.25 kg)

Omax M82ES Series Specifications

General

Brand	Omax
Model	M82ES Series
Category	Microscope
Language	English
