Omax MD827S30 series User Manual

www.microscopenet.com
- 10 -
4 Specifications
Model
MD827S30 series
Total Magnification
40X, 80X, 100X, 200X, 400X, 800X, 1000X, 2000X
Viewing Head
Binocular, 45º inclined, 360º swiveling w/ built-in camera
Interpupillary Distance
Sliding adjustment, 2-3/16” ~ 2-15/16” (55mm ~ 75mm)
Diopter Adjustment
On both eyepiece tubes
Eyepieces
1 pair of WF10X/18
1 pair of WF20X
Objective Tube Length
160mm
Nosepiece
Revolving quadruple
Objectives
Achromatic DIN 4X, 10X, 40X(spring), 100X(spring, oil)
Condenser
Abbe, NA=1.25, w/ iris diaphragm and filter holder
Rack and pinion adjustment
Focus Mechanism
Coaxial coarse and fine focusing knobs on both sides w/
focus stop
Minimum fine focusing adjustment at 0.002mm, range 28mm
Mechanical Stage
Double layer, Dimension: 5-1/2” x 5-1/2” (140mmx140mm)
Translational range: 3” x 2” (75mm X 50mm)
Camera
Built-in USB2.0 2048 x 1536 pixel (3.0MP)
Driver and Software included in the CD
Compatible with Windows 2000, XP, Vista and Windows7
(32/64-bit)
Darkfield Condensers (optional)
Refer to the Darkfield Condensers specifications
Phase Contrast Kits (optional)
Refer to the Phase Contrast kits specifications
Carrying Case (optional)
Net weight: 10 lbs 8 oz (4.75 kg)
Size: 16-1/2" x 12-1/2"x 13-3/8" (42cm x 32cm x 34cm)
Illumination
Transmitted: 6V/20W, Halogen, Variable intensity
Power Supply
AC 100V-240V, 50/60HZ (US and Canada plug)
Dimension
7-7/8” x 10-1/4” x 15-3/8” (20cm x 26cm x 39 cm)
Net weight
12 lbs (5.45 kg)
