Omax MD827S30 series User Manual

www.microscopenet.com
- 3 -
1 Components Illustration
1
Eyepiece
10
Viewing Head w/ Camera
19
Power Switch
2
Diopter Ring
11
Head Thumb Lock Screw
20
Condenser Lock Thumb Knob
3
Eyepiece Tube
12
Microscope Body
21
Condenser Focus Knob
4
Nosepiece
13
Focus Tension Ring
22
Focus Stop Lever
5
Objective
14
Coarse Focus Knob
23
Abbe Condenser
6
Slide Holder
15
Fine Focus Knob
24
Color Filter Holder
7
Mechanical Stage
16
X-Y Stage Moving Knobs
25
Iris Diaphragm Lever
8
Light Collector
17
USB Cable
9
Microscope Base
18
Brightness Intensity Dial
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
20
22
23
19
24
25
21

Omax MD827S30 series Specifications

General

Brand	Omax
Model	MD827S30 series
Category	Microscope
Language	English
