Omax MD82ES10 User Manual

www.microscopenet.com
8
4 Specifications
General
Model
MD82ES10
Total Magnification
40X, 80X, 100X, 200X, 400X, 800X, 1000X, 2000X
Viewing Head
Binocular, inclined 45º, 360º swiveling with Built-in camera
Interpupillary Distance
Sliding adjustment, 2-3/16” ~ 2-15/16” (55mm ~ 75mm)
Diopter Adjustment
On both eyepiece tubes
Eyepieces
1 pair of wild field WF10X/18
1 pair of wild field WF20X
Nosepiece
Revolving quadruple
Objectives
Achromatic DIN 4X/0.10 160/0.17
10X/0.25 160/0.17
40X/0.65 160/0.17(spring),
100X/1.25 160/0.17(spring, oil)
Condenser
Abbe, NA=1.25, w/ iris diaphragm and diffusion filter
Rack and pinion adjustment
Focus Mechanism
Coaxial coarse and fine focusing knobs on both sides
with rack stop
Mechanical Stage
Double layer, dimension: 4-1/2” x 4-15/16”(115 mm x 125 mm)
X-Y translational range: 2-13/16” x 1-3/16” (70 mm x 30 mm)
Illumination
Transmitted, LED, variable intensity
Camera
Built-in USB2.0 1280 x 1024 pixel (1.3MP)
Driver and Software included in the CD
Compatible with Windows 2000, XP, Vista
and Windows 7 32/64-bit
Dry Darkfield Condensers
(optional)
Refer to the Dry Darkfield Condensers Installation & Operation
Instruction
Power Supply
AC/DC adapter, 100V-240V,
Dimension
9-1/16” x 7-1/8” x 13” (23cm x 18cm x 33cm)
Net weight
7 lbs 5 oz (3.32 kg)
