CORRECTION FACTORS
To calculate the correct capacity of a given filter based on actual operating conditions, multiply the nominal
flow capacity by the appropriate correction factor(s).
CORRECTED CAPACITY = NOMINAL FLOW CAPACITY x C
OP
x C
OT
x C
D
OPERATING PRESSURE
[bar] 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
[psi] 29 44 58 72 87 100 115 130 145 160 174 189 203 218 232
C
OP
0,38 0,5 0,63 0,75 0,88 1 1,13 1,25 1,38 1,50 1,63 1,75 1,88 2,00 2,13
OPERATING TEMPERATURE DEW POINT
[°C] 25 30 35 40 45 50 55 60
[°C] -25 -40 -70
[F] 77 86 95 104 113 122 131 140 [F] -13 -40 94
C
OT
1 1 1 0,97 0,87 0,80 0,64 0,51 C
D
1,1 1 0,7
Technical datasheet is available. For additional technical specification contact the
manufacturer.
