Appendix A - Technical Specifications
Page 100 09/11/2008 REV 0.99
Thermocouple: Per ITS90 Resolution 0.1°C
Thermocouple burnout detection - automatic
Type Range (°C) Accuracy (°C) Range (°F) Accuracy (°F)
J -210 to -100 °C ±2.5 °C -340 to -150 °F ±5 °F
-100 to 1200 °C ±1.5 °C -150 to 2190 °F ±3 °F
K -270 to -100 °C ±2.5 °C -450 to -150 °F ±5 °F
-100 to 1372 °C ±1.5 °C -150 to 250 °F ±3 °F
T -270 to -100 °C ±2.5 °C -450 to -150 °F ±5 °F
-100 to 400 °C ±1.5 °C -150 to 750 °F ±3 °F
E -270 to -100 °C ±2.5 °C -450 to -150 °F ±5 °F
-100 to 1000 °C ±1.5 °C -150 to 1832 °F ±3 °F
N -270 to -100 °C ±2.5 °C -450 to -150 °F ±5 °F
-100 to 1300 °C ±1.5 °C -150 to 2372 °F ±3 °F
S -50 to 1768 °C ±3 °C -58 to 3200 °F ±6 °F
B 0 to 1820 °C ±4 °C 32 to 3300 °F ±7 °F
Reference junction compensation accuracy ±0.5 °C (0 °C to 50 °C)
RTD: Base accuracy 0.2% or 0.5 °C (1 °F). Resolution 0.1 °C.
2, or 3 wire connection. Cable compensation to +50 Ohm. Open and short-circuit detection.
10 ohm Cu. -70 to 170 °C -94 to 338 °F
100 ohm Pt. 385 -220 to 850 °C -364 to 1560 °F
100 ohm Pt. 392 -180 to 820 °C -292 to 1500 °F
200 ohm Pt. 385 -220 to 400 °C -364 to 750 °F
200 ohm Pt. 392 -180 to 400 °C -292 to 750 °F
100 ohm Ni. -70 to 300 °C -94 to 570 °F
120 ohm Ni. -70 to 300 °C -94 to 570 °F
1000 ohm Ni. -60 to 209 °C -76 to 408 °F
FREQUENCY: 2 or 4 channels 0 to 5000Hz all channels (0 to 10,000Hz 1 channel alone). Input on
channels 1, 6, 7 and 12 only.
Accuracy: +1Hz
Input Voltage: +5 to +12Vdc or +12 to +24Vdc @ 20mA (User Selectable)
