Appendix A - Technical Specifications
Page 101 09/11/2008 REV 0.99
RECORDING
Recording Rates User programmable from 10 samples per second to 1 sample every 99 hours.
Data Format Proprietary encrypted format. User File naming.
Data Storage Capacity Data stored in non-volatile RAM and recorded automatically to
Removable Media Types Industry Standard removable Compact Flash to 2GB
Industry Standard USB Flash Drives to 2 GB
Internal Media Industry Standard SD card (internal memory) to 1GB
File types Data files, Alarm and Event files, Configuration files, Language Files, Multiple files of
different names on a single disk.
COMMUNICATIONS
Network 10/100 Base T Ethernet per 802.3. RJ45 Connection standard
Servers Webserver supports http and ftp protocols
OPC server
Modbus Over Ethernet Server
Serial (Option) Isolated RS485/RS232 Modbus Interface
INPUT / OUTPUT OPTION
Outputs Optional: Up to 12 x Relay out Form A (normally open SPST contacts) rated at 200Vdc
Current :0.5A Max Power: 10 watt MAX
Inputs Up to 6 optically isolated inputs
+5 to +12 Vdc or +12 to +24Vdc @ 20mA (User Selectable)
DESIGN ATTRIBUTES
Operating Range 0°C to 50°C, 10% to 80% RH
Protection IP65 when mounted in panel
Safety Meets the requirements of UL-3111-1 and EN61010- 1 when installed in accordance with
the instruction in the manual.
UL and cUL approved – Pending
Other 21CFR11 compliant
EMC Meets the requirements of EN61326:1998 and CE directive 89/336/EEC
Input Voltage 100 to 240 Vac, 50/60 Hz or 125 Vdc @ 35VA max.
PHYSICAL PARAMETERS
Dimensions 174mm D x 144mm H x 144mm W (excluding rear connections)
6.85‟‟ D x 5.67‟‟ H x 5.67‟‟ W (excluding rear connections). See Installation detail.
Weight Approx. 2.5kg (5.6lbs) - weight will vary depending on options installed
