30
ANALOG OUTPUT ENABLE/DISABLE SUBMENU:
Press
b
5) Scroll though the available selection until
ENBL
displays to
use Analog Output Retransmission (output proportional to the
input signal).
Press
d
6) Display shows
STRD
stored message momentarily and then
advances to
CURR
or
VoLT
Submenu only if it was changed,
otherwise press a to advance to
CURR
or
VoLT
Current/Voltage Submenu.
If
DSBL
Analog Output Disabled was selected, all submenus of Analog
Output Menu will be skipped and the meter will advance to
ALR2
Alarm 2
Menu. If
ENBL
Analog Output Enabled was selected, Output 1 would be
automatically Disabled, and reassigned as Analog Output.
CURRENT/VOLTAGE SUBMENU:
Press
d
7) Display flashes
CURR
Current or
VoLT
Voltage.
Press
b
8) Scroll through the available selection: Current or Voltage
(Example
VoLT
).
Press
d
9) Display shows
STRD
stored message momentarily and then
advances to
RD1
Submenu only if it was changed, otherwise
press
a
to advance to
RD1
Reading 1 Submenu.
READING 1:
Press
d
10) Display flashes 1
st
digit of previous “Reading 1” value.
Press
b
&
c
11) Enter “Reading 1” value. (Example 0000)
Press
d
12) Display advances to
OUT.1
Out 1 Submenu.
OUT 1:
Press d 13) Display flashes 1
st
digit of previous “Out 1” value.
Press b & c 14) Enter “Out 1” value. (Example 00.00)
Press d 15) Display advances to RD!2 Reading 2 Submenu.
READING 2:
Press
d
16) Display flashes 1
st
digit of previous “Reading 2” value.
Press
b
&
c
17) Enter “Reading 2” value. (Example 9999)
Press
d
18) Display advances to
OUT.2
Out 2 Submenu.
OUT 2:
Press
d
19) Display flashes 1
st
t
digit of previous “Out 2” value.
Press
b
&
c
20) Enter “Out 2” value. (Example 10.00)
Press
d
21) Display advances to the
ALR2
Alarm 2 Menu.
The above example is for 0-10 V of the entire range of the Process Input
and Analog Output. For 0-20 mA output you need to set “Analog Type” to
Current and OUT 2 to 20.00.
